ESD Conductive Rubber Turntables – Eurostat
- Part number: 44-310-5120
ESD Conductive Rubber Turntables – Eurostat
Eurostat ESD conductive rubber turntables allow 360° rotation of sensitive electronic components and equipment in EPA zones without lifting or repositioning. Their conductive rubber surface ensures charge dissipation during handling.
- ✓ Surface material: conductive rubber
- ✓ Disc material: plastic
- ✓ Surface resistance: ≤ 10⁶ Ω
- ✓ Volume resistivity: ≤ 10⁷ Ω
- ✓ 360° rotation for component handling in EPA zones
- ✓ Avoids lifting and repositioning parts during inspection or assembly
- ✓ IEC 61340-5-1 compliant
Features
-
Conditioning
Single unit
-
Surface resistance
RS < 10^6 Ohm
-
Material
conductive rubber (tray) - plastic (disc)
-
Diameter
380 mm
-
Maximum load capacity
8 kg
